LinkMap
™
with Pass/Fail
4
OTDR Software Options
M series OTDR LinkMap with Pass/Fail enables even novice users to easily and accurately
troubleshoot optical networks. LinkMap presents an icon-based view of the tested network clearly
identifying ber start, end, connectors, splices and macro-bends. A LinkMap Summary provides
end-to-end link length, loss, and ORL. Loss and reectance of detected events is compared to
industry-standard or user-settable pass/fail thresholds and displayed with clear pass/fail indications.
LinkMap feature is only available on M310 OTDR.
TruEvent
™
Event Analysis Technology
The M series OTDRs utilize AFL’s industry leading TruEvent technology to provide a new level of
accuracy and reliability in event analysis. Events on a ber include connectors, splices, optical
splitters and macro-bends. To accurately locate an event, OTDRs need to nd its location, identify
event type, measure reectivity and loss. M series OTDRs with TruEvent technology provide better
baseline documentation of ber links and enables the user to troubleshoot faulty networks more
effectively.
TRM (Test Results Manager) trace analysis and reporting PC Software
• A CD containing TRM 2.0 is included with every OTDR. The CD jacket has a sticker with a license
activation key for TRM Basic Software (OTDR Trace/OLTS viewer, Batch Editor, and Reports). The
activation key is good for up to ve fulllments to allow multiple PCs to run TRM 2.0 Basic.
The multiple fulllments also allows a user to activate TRM 2.0 Basic when changing to a new
PC. Once the ve fulllments have been used for a license key, the user must purchase a new
license, which will provide a new activation key good for ve fulllments.
• To install TRM Basic on additional PCs, additional licenses of TRM Basic Software may be
purchased by ordering part number TRM-00-0900PR.
• A single license version of TRM Advanced Software (incudes TRM Basic plus Advanced Analysis
for PC) may be purchased by ordering part number TRM-00-0910PR. TRM Advanced Software is
included in M310 OTDRs.
• To upgrade from TRM Basic to TRM Advanced software a single license version may be
purchased by ordering part number TRM-00-0920PR.
DFS1 Digital FiberScope
When a DFS1 hardware kit is ordered, the berscope can be plugged in M series OTDR and ready
for use.
This is a user’s guide for the M310 and M210e OTDRs. It assumes basic
knowledge in the use of an OTDR, OPM, and a PC.
