52
Enable Bi-directional Analysis Feature (see “Navigating Through Event Setting Menu” on page
22 for details).
In the example screens below:
– End 1 location is named ‘MDF’;
– End 2 location is named ‘IDF’
– Route name is ‘MDF_IDF’
1. Test the complete cable from the rst end at one or more wavelengths as needed.
Test from End 1:
• Connect OTDR to a cable to be tested at End 1.
• In the Job Setting page, set the ‘OTDR Located At’ parameter to End 1
A
.
• Notice that Home page indicates OTDR location at MDF
B
.
• Test each ber (1 to X bers) at End 1.
• Notice that the Trace page header displays “Not Saved” status and the currently tested ber
name “MDF-IDF-SM 12F_001”
C
indicating test direction “MDF-IDF”.
• Press the Save key to save the currently displayed test result.
Note: Save each ber test result before proceeding to the next ber number.
• Notice that the Trace page header changes to display “Saved”
D
.
Important: Save End 1 and End 2 test results in the same ber le.
Test the Complete Cable in One Direction
Bi-directional Analysis Operation
Applies only for M310 with the licensed Advanced Analysis software option installed
Home page indicates
OTDR location at MDF.
Job Settings page
indicates OTDR
location at End 1.
A
B
Trace page header displays “Not
Saved”status and the current
trace name indicating test
direction “MDF-IDF”.
C
D
“Saved” status is displayed after
test is saved.
To Next Page
