Setup Parameters Available in Real-Time Mode
In the Real-Time OTDR test mode, these parameters may be set as indicated below:
Parameter Option Description
Front Panel
Check
On
Enables OTDR to check the quality of the connection at the OTDR
front panel and provides on-screen suggestions for corrective actions
if the Front Panel connector is BAD or FAIR (see “Front Panel and
First Connector Check” on page 37 for details).
Off Disables the OTDR Front Panel connection check.
First
Connector
Check
On
Enables OTDR to check the quality of the rst connection at ber
under test and provides on-screen suggestions for corrective actions
if the First Connector is BAD or FAIR (see “Front Panel and First
Connector Check” on page 37 for details).
Off Disables the First Connector check.
Event Thresholds and Pass/Fail Thresholds are not used during real-time testing.
Event Settings
