AFL M210e User Manual

41
Event Icon Event Type
Reective event (i.e. connector) Pass
Reective event (i.e. connector) Fail
Reective event (information only, not evaluated)
Closely spaced event Pass
Closely spaced event Fail
Closely spaced (information only, not evaluated)
Macrobend Pass
Macrobend Fail
Macrobend (information only, not evaluated)
Link Start Pass
Link Start Fail
Link End Pass
Link End Fail
Link End (Information only)
Non-reective event (i.e. splice) Pass
Non-reective event (i.e. splice) Fail
Non-reective event (i.e. splice) (information only, not evaluated)
Gainer Pass
Gainer Fail
Gainer (information only, not evaluated)
Launch cable
Receive cable
Arrows (indicating more events)
Event Icons and Types
OTDR Test Results Viewer
