121
GUIDANCE
• Press to mark point B. The AB line appears on the map screen and point B is marked
with a red ball.
Note: Guidance extends beyond the end of curved swaths. This makes it possible to get LED guidance back
onto the swath if the vehicle drives past the end of a swath. The extended swath lines do not appear on screen.
Press: Map button > Guidance tab (in Mapping Toolbox) > Setup (wrench) button > Adaptive Curve tab
• You can adjust the degree heading at which the
system generates the next pass by doing the following:
Go to the Guidance screen and press the Options
button. The Guidance Options screen appears; press
the Adaptive Curve button. At the New Pass drop-down
menu, select Heading Change, then use to
enter in the degree number of your Heading Threshold.
Patterns are automatically saved when the vehicle
turns for the first time. For more information see
“AutoSave” on page 127.
IDENTICAL CURVE
Use the Identical Curve pattern to follow gentle
contours in the field. This pattern provides guidance
based on the original curve driven.
Select Pattern
Adaptive Curve
Nudge
Adaptive Curve
Shift
Lightbar
Save
Pause
New Pass
Heading Threshold
Heading Change
100
Guidance Options
Save
Group
New
Pattern
To Next Page
