PLANTING
RATE CONTROL
Control Valve Settings - Servo
• Valve Response 1
Determines the speed of the servo valve when product
control error exceeds the Response Threshold setting.
• Valve Response 2
Determines the speed of the servo valve when product
control error is less than the Response Threshold
setting.
• Response Threshold
Determines the system responsiveness to rate change.
Auxiliary Tab settings
• Minimum Ground Speed
The display will simulate this specific ground speed
when either the jump start switch is pressed or the
motion detection sensor disengages. This fixed ground
speed setting compensates for delays in acquiring an
initial ground speed when starting from a stand still. The
setting determines the target seed meter RPM when the
setting is active.
• Rate Not Responding Threshold
The percentage of seed rate error that triggers the alarms.
• Rate Not Responding Time
The amount of time that the error occurs before the alarm sounds.
Valve
Response 1
Valve
Response 2
Controller Valve Settings
Servo
40 %
Response Threshold
15
8 %
Control Valve
2 mph
Rate Not Responding
Threshold
Rate Not
Responding Time
Minimum Ground Speed
Channel 1
Auxiliary
30 %
4 s
Controller Settings
