145
GUIDANCE
ONTRAC2+
3. Use the Steering Command buttons to send the various commands to the MDU. Observe that the
steering wheel behaves according to the specified command.
Note: The command buttons control the rate at which the wheels turn left/right.
• Hard Left button — turns wheel left at 100%
• Percent Left button — turns wheels left at amount specified in slider bar
• Zero Percent button — stops wheels from turning
• Percent Right button — turns wheels right the amount specified in the slider bar
• Hard Right button — turns the wheel right at 100%
• Stop button — terminates the Steering Diagnostics procedure
• Steering Left/Right Percentage — changes turning speed (the higher percentage turning faster)
SYSTEM MENU
Press: System button
The system menu features the following functions:
monitor system parameters and performance
save, delete, or reset information in system database and log files
activate or deactivate optional sensors
password protected for use by qualified service technicians only.
upgrade system with the latest software available.
SYSTEM HEALTH
Press: System button > System Health button
The System Health screen provides diagnostic and status information for various aspects of steering
system. The overview screen displays the status of the components. Select an item for which you want a
detailed status.
System
System Health
Manage
Accessories
Technician
Software
Upgrade
System
System Health
To Next Page
