201

PLANTING

SEED TUBE MONITOR MODULE

VIRTUAL SEED TRENCH

The virtual seed trench shows the placement of each seed of a problematic row to help determine

if the problem is in the seed meter or seed tube. The yellow and red indicators show where there

are seeding errors. The display does not log this information

• Double Skip Poor Spacing

• Play/Resume button

• Pause button

• Zoom In button

• Zoom Out button

Default Chapter3
