183
PLANTING
DOWN FORCE
Hydraulic Pressure to Down Force Conversion adjusts system to accurately display changes to
hydraulic down force. This setting is row unit specific.
Force Conversions
Gauge Wheel Load Sensor is the type of gauge wheel load sensor used. This is specific to the make of
your planter.
Uplift Force is usually 0 unless planter is equipped with uplift springs to provide an upward force on row
units.
Maximum Force is used to limit the down force created by the actuator. The default is 450 lbs same as
the factory airbag.
Gauge Wheel Load Alarm sets alarm to notify operator when system goes below Minimum Gauge
Wheel Load for a set amount of time (Time Threshold).
Down Force Channel 1 and Channel 2 tabs
The pressure and duty cycle settings are to help the display control the hydraulics. The defaults should
be correct.
Hydraulic Pressure (Grayed out for Monitor Only).
Planter Type
Pressure
Conversion
Deere Short Arm 4.5 psi/lb
Deere Long Arm 3.8 psi/lb
Kinze 3000 4.2 psi/lb
Operating Limits
Pressure Duty Cycle
Ag Leader Valve Block Calibration
Minimum 100 0
Medium 550 20
Maximum 2800 65
Down Force
Channel 1
General
Channel 2
Hydraulic Pressure
Minimum
Medium
Maximum
Duty Cycle
Minimum
Medium
Maximum
Row Unit Sensors
Sensor 1
Sensor 2
Sensor 3
Sensor 4
Calibrate
Pressure Sensor
Pressure Sensor
Enable
0
20
65
200
PWM
Frequency
100
550
2800
