Ag Leader Technology Integra User Manual

240 Firmware Version 5.2
Case IH 4260 with
KZKCO valve
Non-AIM
Command Mode
By-Pass Servo
2% 40% 10% 5
Case IH 3150 with
Raven valve
Non-AIM
Command Mode
In-Line Servo
2% 100% 24% 3
Case 3185 with
Raven valve
Non-AIM
Command Mode
In-Line Servo
2% 100% 24% 3
Case IH 3310
Non-AIM
Command Mode
PWM 12-Volt
122
**700-
900
30 2%
Case IH 4410
Non-AIM
Command PWM
12-Volt
122
**700-
900
30 2%
GVM Prowler
(2007)
Pump Servo 2% 100 24 10
GVM Predator Servo 2% 100% 24%
**See
note
below
Hagie 284, 284XP,
DTS-8
Pump Servo 2% 100% 24% 3
Hagie 2100, 2101,
DTS-10
Pump Servo 2% 100% 24% 3
Hagie STS 10, 12,
(2000 to 2005)
Pump Servo 2% 100% 24% 20
Hagie STS 10, 12,
14, 16 (2006 and
up)
PWM 12-volt 122
**350-
600
20 2%
Hagie 39-pin
Spray II switch box
(2006 and 2007)
Calibrated Reflow 2% 100% 40% 2
John Deere 4700,
47X0, 49X0
No rate control
provided
Miller Nitro N1 and
N2
Pump Servo 2% 100% 24% 20
Flow Control Valve
or Sprayer Model
(and year if
applicable)
Control System
PWM Frequency
Typical Gain Range
Zero Offset
Allowable Error
Valve Response
1
Valve Response
2
Response Threshold
