Agilent Technologies 1260 - Page 215

Agilent 1260 Infinity DAD and MWD User Manual 215
Maintenance
10
Replacing Capillaries on a Semi-Micro and Micro Flow Cell
1
Identify the inlet and outlet capillaries. 2 After replacing the outlet capillary, fix it handtight first.
Then do a 1/4 turn with a 4-mm wrench.
3 To replace the inlet capillary, use a 4-mm wrench for the
fitting.
4 Unscrew the cell body from the heat exchanger and the
heat exchanger from the clamp unit.
>caZiXVe^aaVgn
DjiaZiXVe^aaVgn
