50 Agilent 1260 Infinity DAD and MWD User Manual
3 Installing the Module
Installing the Detector
Installing the Detector
All modules in the stack should have the latest firmware installed. If other
revisions are required, check with the Agilent support for best match.
Parts required Description
Power cord
LAN cable (cross-over or twisted pair network cable)
Hardware required Detector (as ordered)
Software required Appropriate control software or G4208A Instant Pilot (optional).
Preparations Locate bench space
Provide power connections
Unpack the module
WARNING
Module is partially energized when switched off, as long as the power cord is
plugged in.
Repair work at the module can lead to personal injuries, e.g. shock hazard, when the
cover is opened and the module is connected to power.
➔ Make sure that it is always possible to access the power plug.
➔ Remove the power cable from the instrument before opening the cover.
➔ Do not connect the power cable to the Instrument while the covers are removed.
NOTE
Before adding a G1315C/D and G1365C/D into an existing system assure that the existing
modules have been updated to firmware revision A.06.02/B.01.02 or above. Otherwise the
ChemStation “Performance Specifications” on page 38 will not recognize modules.
NOTE
For G1315C and G1365C assure that the CompactFlash Card is installed in the rear of the
module (required for operation).
