200 Agilent 1260 Infinity DAD and MWD User Manual
10 Maintenance
Exchanging a Flow Cell
Exchanging a Flow Cell
When If an application needs a different type of flow cell or the flow cell needs repair.
Tools required Two 1/4 inch wrenches for capillary connections
Parts required # p/n Description
1 G1315-60022 Standard flow cell, 10 mm, 13 µL, 120 bar (12 MPa)
1 G1315-60025 Semi-micro flow cell, 6 mm, 5 µL, 120 bar (12 MPa)
1 G1315-60024 Micro flow cell, 3mm, 2µL, 120bar (12MPa)
1 G1315-60015 High pressure flow cell, 6 mm, 1.7 µL, 400 bar (40 MPa)
1 Nano flow cell, refer to “Nano Flow Cell - Replacing or Cleaning” on page 218
Preparations Turn the lamp(s) off.
Remove the front cover.
1 Press the release buttons and remove the front cover to
gain access to the flow cell area.
2 Open the flow cell cover.
