242 Agilent 1260 Infinity DAD and MWD User Manual
11 Parts for Maintenance
Prep Flow Cell - Quartz
Prep Flow Cell - Quartz
NOTE
For more details on the Preparative Flow Cells refer to the technical note that comes with
the flow cells.
Item p/n Description
G1315-60017 Prep flow cell quartz, 0.3 mm, 20 bar (2 MPa)
G1315-60018 Prep flow cell quartz, 0.06 mm (2 MPa)
1 G1315-67301 PTFE tubing 2 m length, 0.8 mm i.d., o.D. 1.6 mm
G1315-67302 PTFE tubing 80 cm length, 0.5 mm i.d., o.D. 1.6 mm
2 0100-1516 Fitting male PEEK, 2/pk
3 G1315-27705 Cell housing
4 G1315-84901 Clamp unit
5 G1315-84902 Handle for Clamp unit
6 0515-1056 Screw M 2.5, 4 mm lg
for cell body/clamp
7 G1315-80004 Quartz body - Prep Cell 0.3 mm
7 G1315-80003 Quartz body - Prep Cell 0.06 mm
NOTE
The flow cell comes with two tubings 0.8 mm i.d. and one 0.5 mm i.d. so that the
combination at the flow cell could be either 0.8/0.8 or 0.5/0.8 (inlet/outlet).
Standard is 0.8/0.8. Depending on the system pressure (<30 mL/min) or bandbroadening,
the inlet tubing might be changed to 0.5 mm.
