Chapter 11: Site Preparation – Series 3 / 79000 Current Reduction Conversion: Series 3 Current Reduction Conversion Procedure
Single-Phase
Non-Earthed
AWX 200 220V
0EB 220 220V
0EJ 230 240V
0EC 240 240V
Single-Phase Center-Tap
Neutral
AWY 100 / 200 220V
0E3 110 / 220 220V
0EG 115 / 230 240V
0EH 120 / 240 240V
Table 11-3 DUT power supply line voltage setting (single-phase) (continued)
System Power
Option
Voltage DUT Supply
Line Voltage
L1
L2
G
L1
L2
G
N
