5-22 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Print/Plot Function
Saving Screen Images
To save the screen images:
1. Display the screen that you want to print out, then press:
a. the front-panel green key
b. Plot/Print key
The 4155C/4156C displays the SCREEN DUMP dialog box.
In this dialog box, three softkeys are available:
PRINT/PLOT Executes the screen image save.
PR/PL SETUP Displays the PRINT/PLOT SETUP screen. To close the
PRINT/PLOT SETUP screen, select EXIT softkey.
EXIT Closes the SCREEN DUMP dialog box and quits the
print/plot function.
2. To set the DESTINATION to FILE, select FILE softkey.
3. Enter the file name in the FILE NAME field.
To save a file to a diskette in the built-in flexible disk drive, the file name must
be:
• a maximum of 8 characters for DOS format
• a maximum of 6 characters for HP LIF format (Do not use "_" as the last
character of the filename.)
To save a file to the network drive, the file name can be a maximum of 36
characters. The file name and directory path can be a maximum of 58 characters.
SCREEN DUMP
*OUTPUT REGION
*DESTINATION
*LANGUAGE
LOWER RIGHT
FILE
UPPER LEFT X 5%
X 100%
Y 0%
Y 100%
PCL
*RESOLUTION
75 DPI
*FILE NAME
