Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-23
Print/Plot Function
Saving Screen Images
4. To set the LANGUAGE, select PCL, HR PCL, HP-GL, TIFF or HR TIFF
softkey.
If you select PCL, HR PCL, or HR TIFF mode, set the RESOLUTION by
selecting one softkey: 75 DPI to 600 DPI. For more information on selecting
resolution, see “Output Resolution” on page 5-5.
If you select the HR PCL mode, setting the resolution too low will result in poor
print quality.
5. If you select HR PCL or HP-GL, set the OUTPUT REGION. There are two
available fields:
UPPER LEFT Specifies the position of the upper-left corner of the printed
or plotted hard copy.
LOWER RIGHT Specifies the position of the lower-right corner of the
printed or plotted hard copy.
Select one of the following softkeys, or enter a value using the keyboard or the
ENTRY keys on the front panel. These softkeys are available for each OUTPUT
REGION field:
WHOLE Sets the output region as the entire sheet.
UPPER LEFT Sets the output region to the upper-left quarter of the
paper.
UPPER RIGHT Sets the output region to the upper-right quarter of the
paper.
LOWER LEFT Sets the output region to the lower-left quarter of the
paper.
LOWER RIGHT Sets the output region to the lower-right quarter of the
paper.
STORE REGION Stores the OUTPUT REGION settings in the internal
memory.
RECALL REGION Recalls the latest settings stored in the internal memory.
To set the output region to the upper half of the paper, the OUTPUT REGION
should be defined as follows:
*OUTPUT REGION
UPPER LEFT X 0% Y0%<--origin of printer
LOWER RIGHT X 100%
Y 50%
6. To start to save the screen image, select PRINT/PLOT softkey.
7. To close the SCREEN DUMP dialog box, select EXIT softkey.
