Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-25
Print/Plot Function
Saving Setup Data Lists
To save the setup data list:
1. Display the setup screen you want to save, then press:
• Plot/Print key
The 4155C/4156C displays the PRINT/PLOT SETUP DATA dialog box:
In this dialog box, three softkeys are available:
PRINT/PLOT Executes the file save.
PR/PL SETUP Displays the PRINT/PLOT SETUP screen. To close the
PRINT/PLOT SETUP screen, select EXIT softkey.
EXIT Closes the PRINT/PLOT SETUP DATA dialog box and
quits the print/plot function.
2. To set the DESTINATION to FILE, select FILE softkey.
PRINT/PLOT SETUP DATA
*DESTINATION
*LANGUAGE
PCL*PRINT/PLOT COMMENT
*OUTPUT PAGE CURRENT
*RESOLUTION
75 DPI
FILE *FILE NAME
PRINT/PLOT SETUP DATA
*DESTINATION
*LANGUAGE
HP-GL*PRINT/PLOT COMMENT
*OUTPUT PAGE CURRENT
FILE *FILE NAME
*OUTPUT REGION
LOWER RIGHT
UPPER LEFT X 5%
X 100%
Y 0%
Y 100%
