Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-27
Print/Plot Function
Saving Setup Data Lists
STORE REGION Stores the OUTPUT REGION settings in the internal
memory.
RECALL REGION Recalls the latest settings stored in the internal memory.
To set the output region to the upper half of the paper, the OUTPUT REGION
should be defined as follows:
*OUTPUT REGION
UPPER LEFT X 0%
Y0%<--origin of printer
LOWER RIGHT X 100% Y 50%
7. Optional: Enter a comment of up to 58 characters in the PRINT/PLOT
COMMENT field. This comment is printed only when this field is enabled on
the SYSTEM: PRINT/PLOT SETUP screen.
8. To start the file save, select PRINT/PLOT softkey.
9. To close the PRINT/PLOT SETUP DATA dialog box, select EXIT softkey.
