Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 5-29
Print/Plot Function
Saving Measurement Data Lists
To save the measurement result list:
1. Display the GRAPH/LIST: LIST screen, then press:
• Plot/Print key
The 4155C/4156C displays the PRINT/PLOT DATA LIST dialog box.
In this dialog box, three softkeys are available:
PRINT/PLOT Executes the file save.
PR/PL SETUP Displays the PRINT/PLOT SETUP screen. To close the
PRINT/PLOT SETUP screen, select EXIT softkey.
EXIT Closes the PRINT/PLOT DATA LIST dialog box and quits
the print/plot function.
2. To set the DESTINATION to FILE, select FILE softkey.
PRINT/PLOT DATA LIST
*DESTINATION FILE
*PRINT/PLOT COMMENT
*OUTPUT DATA(INDEX NO)
<-->
1 MAX
*LANGUAGE
PCL
*RESOLUTION
75 DPI
*FILE NAME
PRINT/PLOT DATA LIST
*OUTPUT REGION
*DESTINATION FILE
UPPER LEFT X 5%
Y 0%
*PRINT/PLOT COMMENT
*OUTPUT DATA(INDEX NO)
<-->
1 MAX
*LANGUAGE
HP-GL
UPPER LEFT X 100% Y 100%
*FILE NAME
