5-30 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Print/Plot Function
Saving Measurement Data Lists
3. Enter the file name into the FILE NAME entry field.
To save a file to a diskette in the built-in flexible disk drive, the file name must
be:
• a maximum of 8 characters for DOS format
• a maximum of 6 characters for HP LIF format (Do not use "_" as the last
character of the filename.)
To save a file to the network drive, the file name can be a maximum of 36
characters. The file name and directory path can be a maximum of 58 characters.
4. To set the LANGUAGE, select PCL, HR PCL, or HP-GL softkey.
If you select PCL or HR PCL, ignore the RESOLUTION setting. The text font
size depends on the printer you use.
5. Set the OUTPUT DATA (INDEX NO) to be saved.
a. Select the data INDEX numbers 1 to 100, by entering the following:
*OUTPUT DATA (INDEX NO)
1 <--> 100
b. Select all the measurement data by selecting ALL softkey.
6. If you select HP-GL, set the OUTPUT REGION. There are two available fields:
UPPER LEFT Specifies the position of the upper-left corner of the printed
or plotted hard copy.
LOWER RIGHT Specifies the position of the lower-right corner of the
printed or plotted hard copy.
Select one of the following softkeys, or enter a value using the keyboard or the
ENTRY keys on the front panel. These softkeys are available for each OUTPUT
REGION field.
WHOLE Sets the output region as the entire sheet.
UPPER LEFT Sets the output region to the upper-left quarter of the paper.
UPPER RIGHT Sets the output region to the upper-right quarter of the
paper.
LOWER LEFT Sets the output region to the lower-left quarter of the paper.
LOWER RIGHT Sets the output region to the lower-right quarter of the
paper.
