Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 8-11
Specifications
Hardware
Table 8-4 MPSMU Current Range, Resolution, and Accuracy
Current
Range
Set
Reso.
Set Accuracy
a
a. Accuracy: ± (% of reading or setting value + offset value). Vout is the output voltage in volts.
Meas.
Reso.
Measurement
Accuracy
a
Max. Voltage
b
b. Iout is the output current in amps.
± 1 nA 100 fA ± (0.5 % + 3 pA
+2fA× Vout)
10 fA ± (0.5 % + 3 pA
+2fA× Vou t)
100 V
± 10 nA 1 pA ± (0.5 % + 7 pA
+20fA× Vou t)
10 fA ± (0.5 % + 5 pA
+20fA× Vo u t )
100 V
± 100 nA 10 pA ± (0.12 % + 50 pA
+200fA× Vou t)
100 fA ± (0.1 % + 30 pA
+200fA× Vout)
100 V
± 1 μA100 pA± (0.12 % + 400 pA
+2pA× Vo u t )
1 pA ± (0.1 % + 200 pA
+2pA× Vout)
100 V
± 10 μA1 nA ± (0.12 % + 5 nA
+20pA× Vout)
10 pA ± (0.1 % + 3 nA
+20pA× Vout)
100 V
± 100 μA10 nA ± (0.12 % + 40 nA
+200pA× Vou t)
100 pA ± (0.1 % + 20 nA
+200pA× Vout)
100 V
± 1 mA 100 nA ± (0.12 % + 500 nA
+2nA× Vo u t )
1 nA ± (0.1 % + 300 nA
+2n
A× Vout
)
100 V
± 10 mA 1 μA ± (0.12 % + 4 μA
+20nA× Vout)
10 nA ± (0.1 % + 2 μA
+20nA× Vout)
100 V
± 100 mA 10 μA ± (0.12 % + 50 μA
+200nA× Vou t)
100 nA ± (0.1 % + 30 μA
+200nA× Vout)
100 V (Iout ≤ 20mA)
40V
(20mA < Iout ≤ 50mA)
20V
(50mA < Iout ≤ 100mA)
