Agilent Technologies 41501B User Manual

8-12 Agilent 4155C/4156C User’s Guide Vol.1, Edition 11
Specifications
Hardware
Table 8-5 MPSMU Voltage Range, Resolution, and Accuracy
VSU (Voltage Source Unit) Specifications
Same as the 4156C VSU.
VMU (Voltage Monitor Unit) Specifications
Same as the 4156C VMU.
Voltage
Range
Set
Reso.
Set Accuracy
a
a. Accuracy: ± (% of reading or setting value + offset value). Iout is the output current in amps.
Meas.
Reso.
Measurement
Accuracy
a
Max. Current
b
b. Vout is the output voltage in volts.
± 2 V 100 μV ± (0.03 % + 900 μV
+0.3× Iout)
2 μV ± (0.02 % + 700 μV
+ 0.3 × Iout)
100 mA
± 20 V 1 mV ± (0.03 % + 4 mV
+0.3× Iout)
20 μV ± (0.02 % + 2 mV
+0.3× Iout)
100 mA
± 40 V 2 mV ± (0.03 % + 7 mV
+0.3× Iout)
40 μV ± (0.02 % + 3 mV
+0.3× Iout)
100 mA (Vout ≤ 20 V)
50 mA
(20 V < Vout ≤ 40 V)
± 100 V 5 mV ± (0.04 % + 15 mV
+0.3× Iout)
100 μV ± (0.03 % + 5 mV
+0.3× Iout)
100 mA (Vout ≤ 20 V)
50 mA
(20 V < Vout ≤ 40 V)
20 mA
(40 V < Vout ≤ 100 V)
