Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 8-15
Specifications
Hardware
Table 8-7 HPSMU Voltage Range, Resolution, and Accuracy
MPSMU Specifications
Same as the 4155C MPSMU.
GNDU (Ground Unit) Specifications
• Specifications
Output voltage 0 V
± 100 μV
Sink current maximum 1.6 A
Output terminal/connection Single triaxial connector, Kelvin
(remote sensing)
• Supplemental information
Load capacitance
≤ 1 μF
Cable resistance Force
≤ 1 Ω
Sense
≤ 10 Ω
Voltage
Range
Set
Reso.
Set Accuracy
a
a. Accuracy: ± (% of reading or setting value + offset value).
Meas.
Reso.
Measurement
Accuracy
a
Max. Current
± 2 V 100 μV ± (0.03 % + 900 μV) 2 μV ± (0.02 % + 700 μV) 1 A
± 20 V 1 mV ± (0.03 % + 4 mV) 20 μV ± (0.02 % + 2 mV) 1 A
± 40 V 2 mV ± (0.03 % + 7 mV) 40 μV ± (0.02 % + 3 mV) 500 mA
± 100 V 5 mV ± (0.04 % + 15 mV) 100 μV ± (0.03 % + 5 mV) 125 mA
± 200 V 10 mV ± (0.045 % + 30 mV) 200 μV ± (0.035 % + 10 mV) 50 mA
