Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 8-17
Specifications
Hardware
• PGU supplemental information
Overshoot (Undershoot,
ringing)
≤± 5 % of amplitude ± 10 mV
(50 Ω output impedance to 50 Ω load)
Pulse width jitter 0.2 % + 100 ps
Pulse period jitter 0.2 % + 100 ps
Slew rate maximum 100 V/μs
(50 Ω output impedance to 50 Ω load)
Noise 0.2 % of range (at dc output)
Table 8-8 Pulse/dc Output Voltage and Accuracy
Set
Parameter
Voltage
Range
Resolu
-tion
Accuracy
a
a. Accuracy is specified at leading = trailing time = 1 μs.
Base
b
b. dc output is performed by the Base parameter.
± 20 V 4 mV
± (1 % of Base + 50 mV + 1 % of Pulse)
± 40 V 8 mV
± (1 % of Base + 50 mV + 1 % of Pulse)
Pulse ± 20 V 4 mV ± (3 % of Base + 50 mV)
± 40 V 8 mV
± (3 % of Base + 50 mV)
