Agilent 4155C/4156C User’s Guide Vol.1, Edition 11 2-29
Installation
Installing Accessories
Connecting the measurement cables
Connect the measurement cables as shown below.
Instrument Connector Plate
Cable
Model No. Connector Model No. Connector
4155C Intlk 16495H/J Intlk 16493J Interlock Cable
MPSMU 16495H INPUT 1 to 6 Triaxial Cable
16495J INPUT 1 to 8
VSU 16495H INPUT 7 to 12 BNC Cable
16495J INPUT 9 to 12
VMU 16495H INPUT 7 to 12 BNC Cable
16495J INPUT 9 to 12
4156C Intlk 16495H/J Intlk 16493J Interlock Cable
HRSMU 16495H INPUT 1 to 6 Kelvin Triaxial Cable (for
Kelvin) or Triaxial Cable
(for non-Kelvin)
16495J INPUT 1 to 8
VSU 16495H INPUT 7 to 12 BNC Cable
16495J INPUT 9 to 12
VMU 16495H INPUT 7 to 12 BNC Cable
16495J INPUT 9 to 12
41501A/B GNDU 16495H/J GNDU 16493H GNDU Cable
HPSMU 16495H INPUT 1 to 6 Kelvin Triaxial Cable (for
Kelvin) or Triaxial Cable
(for non-Kelvin)
16495J INPUT 1 to 8
MPSMU 16495H INPUT 1 to 6 Triaxial Cable
16495J INPUT 1 to 8
PGU 16495H INPUT 7 to 12 BNC Cable
16495J INPUT 9 to 12
