Agilent Technologies 5000 Series - Page 119

Replaceable Parts 6
5000 Series Oscilloscopes Service Guide 119
H2 0515-0658 4 Screw - machine m2 x 0.4 - 6 mm lg T6 - w/washer
H3 0515-0372 6 Screw - machine m3 x 0.5 - 8 mm lg T10 - w/washer
(secure system board to deck)
H4 0515-0380 3 Screw - machine m4 x 0.7 - 10 mm lg T15 -
w/washer (secure cabinet to chassis, not shown)
H5 0380-0643 2 Standoff - hex 0.255 in. lg 6-32 thread
H6 2190-0068 3 Washer - internal tooth lock 0.505 in. id
H7 2190-0009 2 Washer - internal tooth lock 0.168 in. id
H8 0515-1753 2 Screw - machine m3 x 0.5 - 8 mm lg T10 (use with H9
3050-2336 spring washer)
H9 3050-2336 2 Washer - spring
MP1 54684-42202 1 Hole plug, front panel - 2 ch only
MP2 54684-44101 1 Cover, protective front
MP3 54684-47101 1 Display gasket
MP4 54684-44702 1 Display mount
MP5 54574-43901 1 Extender, power switch
MP6 54574-68501 1 Fan
MP7 54684-44701 1 Fan mount
MP8 54684-41001 2 Foot Pad
MP9 54684-60202 1 Front panel
MP10 54684-41902 1 Keypad, softkey, rubber
MP11 54532-94301 1 ID label 2-ch 100 MHz DSO
MP11 54534-94301 1 ID label 4-ch 100 MHz DSO
Tab le 13 Replaceable Parts (continued)
Ref
Des
Agilent Part
Number Qty Description
