199
Performance Tests
V. Polarization Dependent Loss (PDL): Optional
• Read the power that is displayed on the power meter and
note it as P
DUT01
in the test record.
b. Linear Vertical polarized light.
• Set the
λ/4 and λ/2 Retarder Plates to the "corrected
wavelength dependent positions" for Linear Vertical
polarized light.
You need to select the
λ/4 and λ/2 Retarder plates by
pressing
λ/4 and λ/2 respectively.
Type the appropriate value and press E
NTER after each
entry.
• Read the power that is displayed on the power meter and
note it as P
DUT02
in the test record.
c. Linear Diagonal polarized light.
• Set the
λ/4 and λ/2 Retarder Plates to the "corrected
wavelength dependent positions" for Linear Diagonal
polarized light.
You need to select the
λ/4 and λ/2 Retarder plates by
pressing
λ/4 and λ/2 respectively.
Type the appropriate value and press E
NTER after each
entry.
• Read the power that is displayed on the power meter and
note it as P
DUT03
in the test record.
d. Right Hand Circular polarized light.
• Set the
λ/4 and λ/2 Retarder Plates to the "corrected
wavelength dependent positions" for Right Hand
Circular polarized light.
You need to select the
λ/4 and λ/2 Retarder plates by
pressing
λ/4 and λ/2 respectively.
Type the appropriate value and press E
NTER after each
entry.
• Read the power that is displayed on the power meter and
note it as P
DUT04
in the test record.
