Agilent Technologies 8156A User Manual

239
Performance Tests
V. Polarization Dependent Loss (PDL): Optional
Performance Test for the Agilent 8156A Option 350
Page 4 of 5
Model Agilent 8156A Attenuator Option 350 No. _______________ Date_______________
Test
No.
Test Description
performed at _________________nm
Minimum
Spec. Result
Maximum
Spec.
Measurement
Uncertainty
II. Linearity/Att. Acc. (cont.) ±0.05dB
Attenuation
Setting:
11dB 10.9dB
_________
11.1dB
12dB 11.9dB
_________
12.1dB
13dB 12.9dB
_________
13.1dB
14dB 13.9dB
_________
14.1dB
24dB 23.9dB
_________
24.1dB
34dB 33.9dB
_________
34.1dB
44dB 43.9dB
_________
44.1dB
54dB 53.9dB
_________
54.1dB
60dB 59.9dB
_________
60.1dB
