Manual Adjustment Procedures: 3335A Source not Available
Required Test Equipment
Required Test Equipment
The following table lists the test equipment required to execute the
adjustments in this chapter. These adjustments originally required the
use of the 3335A Synthesizer Level Generator.
Table 3a-1 Recommended Test Equipment
Instrument Critical Specifications for Equipment
Substitution
Recommended
Model
Sources
Synthesized Signal Generator
Frequency range: 250 kHz to 3 GHz
Frequency resolution: 1 Hz
Attenuator resolution: 0.02 dB
Level accuracy: ±0.5 dB
External 10 MHz Ref. Input
E4421B or
E4422B, E4432B,
E4433B
Cables
Cable, 50 Ω coaxial
(four required)
Connectors: BNC (m)
Length: ≥ 122 cm (48 in.)
10503A
Cable Test Cable 85680-60043
Adapters
Adapter
(four required)
Type N (m)-to-BNC (f) 1250-1476
Adapter Type N (f)-to-2.4 mm (f) 11903B
Adapter 2.4 mm (f) to BNC (f) 1250-2187
Adapter
(Option 026 only)
APC-3.5 (f) to APC-3.5 (f) 5061-5311
Adapter
(Option 026 only)
APC-3.5 (f) to BNC-3.5 (f) 1250-1200
To Next Page
