Chapter 1 29
General Information
Instrument Variations
Instrument Variations
There are options available to the 8564EC and 8565EC. The
following table lists these options and identifies the assemblies which
are unique to them.
Table 1-1 Instrument Variations
Option Added Deleted
8564EC and 8565EC
Option 001 (2nd IF Output)
W19 Cable Assembly
Rear-Panel J10
8564EC and 8565EC
Option 005 (add Alternative
Sweep Output)
W58 Cable Assembly
8564EC and 8565EC
Option 006 (Frequency
Coverage Down to 30 Hz)
A8 Low Band Mixer (Opt 006) A8 Low Band Mixer
(Std)
8564EC and 8565EC
Option 008
(SIG ID)
A15 RF Assembly
(Opt 008)
A15 RF Assembly (Std)
8564EC and 8565EC
Option 103 (Delete OCXO)
A15 RF Assembly
(Opt 103)
A15 RF Assembly (Std)
W49 Cable Assembly
W50 Cable Assembly
A21 OCXO
To Next Page
