270 Chapter5
Replaceable Parts
Replaceable Parts
Replaceable Parts
Table 5-4 Replaceable Parts
Reference
Designation
Part
Number
Qty Description Mfr
Code
Mfr Part
Number
ACCESSORIES SUPPLIED
5063-0274 1 FRONT COVER 28480 5063-0274
85620A 1 MASS MEMORY MODULE 28480 85620A
1810-0118 1 TERMINATION-COAXIAL SMA; 0.5W; 50Ω 16179 2003-6113-02
1250-1200 1 ADAPTER, SMA (m) TO BNC (f) 28480 1250-1200
1250-2187 1 ADAPTER, K (f) TO 2.4 mm (f) 28480 1250-2187
1250-2188 1 ADAPTER, 2.4 mm (f) TO 2.4 mm (f) 28480 1250-2188
10502A 1 50Ω COAX CABLE WITH BNC MALE 28480 10502A
8710-1755 3 WRENCH-HEX KEY 55719 AWML4
OPTION 908
5062-0800 1 RACK KIT WITH FLANGES
(Includes Parts Listed Below)
5001-8739 2 PANEL-DRESS 28480 5001-8739
5001-8740 2 PANEL-SUB 28480 5001-8740
5001-8742 2 SUPPORT-REAR 28480 5001-8742
5021-5807 2 FRAME-FRONT 28480 5021-5807
5021-5808 2 FRAME-REAR 28480 5021-5808
5021-5836 5 CORNER-STRUT 28480 5021-5836
0510-1148 10 RETAINER-PUSH-ON KB-TO-SHFT EXT 11591 669
0515-0886 16 SCREW-MACH M3 × 0.5 6MM-LG PAN-HD 28480 0515-0886
0515-0887 8 SCREW-MACH M3.5 × 0.6 6MM-LG PAN-HD 28480 0515-0887
0515-0889 12 SCREW-MACH M3.5 × 0.6 6MM-LG 28480 0515-0889
0515-1241 8 SCREW-MACH M5 × 0.8 12 MM-LG PAN-HD 28480 0515-1241
0515-1331 22 SCREW-METRIC SPECIALTY M4 × 28480 0515-1331
0.7 THD; 7MM
5061-9679 2 MOUNT FLANGE 28480 5061-9679
0515-1114 6 SCREW-MACH M4 × 0.7 10MM-LG PAN-HD 28480 0515-1114
8710-1755 WRENCH-HEX KEY 55719 AWML4
5958-6573 2 ASSEMBLY INSTRUCTIONS 28480 5958-6573
OPTION 909
5062-1900 1 RACK KIT WITH FLANGES AND HANDLES
(Includes Parts Listed Below)
5001-8739 PANEL-DRESS 28480 5001-8739
5001-8740 PANEL-SUB 28480 5001-8740
5001-8742 SUPPORT-REAR 28480 5001-8742
5021-5807 FRAME-FRONT 28480 5021-5807
5021-5808 FRAME-REAR 28480 5021-5808
0510-1148 RETAINER-PUSH-ON KB-TO-SHFT EXT 11591 669
0515-0886 SCREW-MACH M3 × 0.5 6MM-LG PAN-HD 28480 0515-0886
To Next Page
