General Information
Introduction
How to Use this Guide
Chapters 1 through 5 contain adjustments and parts information that
can be used to adjust your spectrum analyzer and to help you fix
problems.
Chapter 6, “General Troubleshooting”, can be used to identify the
location of a problem to a board or functional area in the spectrum
analyzer.
Chapters 7 through 13, which cover functional areas, can then be used
to help you localize the problem further.
Conventions Used in this Guide:
Documentation Outline
8560 E-Series and EC-Series Spectrum Analyzer Calibration Guide
• Tells you how to run verification software.
• Tells you what your spectrum analyzer’s specifications are.
• Tells you how to test your spectrum analyzer.
8560 E-Series and EC-Series Spectrum Analyzer User’s Guide
• Tells you how to make measurements with your spectrum
analyzer.
• Tells you how to install your spectrum analyzer.
• Tells you how to program your spectrum analyzer.
8560 E-Series and EC-Series Spectrum Analyzer Quick Reference
Guide
• Is an abbreviated version of the 8560 E-Series and EC-Series
Spectrum Analyzer’s User’s Guide.
• Provides you with a listing of all remote programming commands.
8560 E-Series Spectrum Analyzer Component Level Information
• Provides schematics and parts lists for the instrument.
Screen Text This font indicates text displayed on the screen
Key This font indicates a softkey or a hardkey
8564E/EC,
8565E/EC
These terms are used to refer to both E-series and
EC-series instruments
