178 Chapter4
Assembly Replacement
Cable Color Code
Cable Color Code
Coaxial cables and wires will be identified in the procedures by
reference designation or name followed by a color code. The code is
identical to the resistor color code. The first number indicates the base
color with second and third numbers indicating any colored stripes. For
example, W23, coax 93, indicates a white cable with an orange stripe.
Table 4-1 Required Tools
Description Part Number
5/16-inch open-end wrench 8720-0015
3-mm hex (Allen) wrench 8710-1366
4-mm hex (Allen) wrench 8710-1164
17-mm socket wrench T362609
No. 4 hex (Allen) wrench 5020-0288
No. 6 hex (Allen) wrench 5020-0289
7 mm nut driver 8710-1217
3/8-inch nut driver 8720-0005
7/16-inch nut driver 8720-0006
9/16-inch nut driver (drilled out, end covered 8720-0008
with heatshrink tubing)
Small No. 1 pozidrive screwdriver 8710-0899
Large No. 2 pozidrive screwdriver 8710-0900
T-8 TORX screwdriver 8710-1614
T-10 TORX screwdriver 8710-1623
T-15 TORX screwdriver 8710-1622
Long-nose pliers 8710-0030
Wire cutters 8710-0012
