Agilent Technologies 8565EC Service Guide

8564/5EC Replacement Parts
A1A1 Bd Assy - Keyboard x x
08563-60181
n/a
A1A2 RPG Assy x x
1990-1525
n/a
A2 Bd Assy - Controller x x
08563-60172
n/a
A3 Bd Assy - Interface x x
08563-60174
n/a
A4 Bd Assy - Log Amp / Cal Osc x x
08563-60163
n/a
A5 Bd Assy - IF Filter x x
08563-60178
n/a
x x
08563-60180
< 4123A (kit with 08564-60034)
x x
08564-60034
>= 4123A
A6A2 Bd Assy - Regulator x x
08564-60030
n/a
A7 LO Multiplier Dist Amp x x
5086-7869
n/a
Low Band Mixer x x
5087-7032
Std
x x
5086-7982
Option 006
A9 Input Attenuator x x
33325-60006
n/a
x -
5086-7930
n/a
- x
5086-7883
n/a
A11 Leveled YTO x x
5086-7906
n/a
A13 Second Converter x x
5086-7957
n/a
A14 Bd Assy - Frequency Control x x
08564-60033
n/a
x x
08563-60186
Standard
x x
08563-60184
Option 103
x x
08563-60186
Option 008 w/o 103
A15U100 Sampler Assy x x
5086-7806
n/a
x x
08563-60180
< 4123A (kit with 08563-60177)
x x
08563-60177
>= 4123A
A17A1 Bd Assy - LCD Inverter x x
0950-3644
n/a
A18 LCD x x
2090-0379
n/a
A18DS1/2 LCD Backlight Tube x x
2090-0380
n/a
A19 Bd Assy - GPIB Interface x x
08562-60042
n/a
A20 Battery Holder Assy x x
5062-7755
n/a
A21 10MHz OCXO Assy x x
5063-0245
Not Option 103
B1 Fan Assy x x
5061-9036
n/a
BT1 Battery - 3.0V Lithium x x
1420-0341
n/a
Fuse - 5A 250V x x
2110-0709
230 VAC Operation
Fuse - 5A 125V x x
2110-0756
115 VAC Operation
FL1 LPF - 2.9GHz x x
0955-0703
n/a
FL2 LPF - 4.4GHz x x
0955-0519
n/a
FL3 LPF - 7.0GHz x x
0955-0721
n/a
FL4 Line Filter Assy x x
5061-9032
n/a
LS1 Loudspeaker Assy x x
9160-0282
n/a
A8
8564EC
8565EC
Part
Number
Conditions
A6
Assy - Power Supply
Reference
Designator
Description
F1
A15
Bd Assy - RF
A17
Bd Assy - LCD Driver
A10/A12
RYTHM/SBTX
