W1
8120-5682
Ribbon Cable - Main Power A6J1 - Power Supply Assembly A2J2 / A3J1 / A4J1 / A5J1 / A14J1 / A15J1
W2 5061-9025 Ribbon Cable - Main Control A3J2 - Interface Board A4J2 / A5J2 / A14J2 / A15J2
W4
8121-0063
Ribbon Cable - Option Module A2J11 - Controller Board Rear Panel J3 - OPTION MODULE
W10 5062-0742 Ribbon Cable - YTO Control A14J3 - Frequency Control Board A11J1 - YTO
W11
08562-60064
Ribbon Cable - Attenuator Control A14J6 - Frequency Control Board A9 - Input Attenuator
W12 5063-0655 Ribbon Cable - LOMA Control A14J10 - Frequency Control Board A7J7 - LOMA
W13
5062-0743
Ribbon Cable - Second Converter Control A14J12 - Frequency Control Board A13J6 - Second Converter
W16 8120-5676 Ribbon Cable - SBTX/RYTHM Control A14J9 - Frequency Control Board A12/A10 - SBTX/RYTHM
W60
8121-0064
Ribbon Cable - Display Control A2J8 - Controller Board A17J1 - Display Driver Board
W63 8120-8409 Ribbon Cable - Display Data A18J1 - LCD A17J5 - Display Driver Board
W64
8121-0062
Ribbon Cable - VGA Output A17J4 - Display Driver Board Rear Panel J1 - VGA OUT
A1A1W1 8121-0065 Ribbon Cable - Keyboard Interface A3J602 - Interface Board A1A1J1 - Front Panel Keyboard
A1A2 1990-1525 Ribbon Cable - RPG Assembly Front Panel - Rotary Pulse Generator A1A1J2 - Front Panel Keyboard
A19W1 5061-9031 Ribbon Cable - GPIB A19J1 - GPIB Board A2J7 - Controller Board
W3
5064-3966
Wire Harness - Line Switch Assembly Front Panel - Line Switch A6J2 - Power Supply Assembly
W6 5062-7755 Wire Harness - Battery Cable / Plate Assembly BT1 - Battery A2J3 - Controller Board
W8
5022-6195
Wire Harness - Display Power A6J5 - Power Supply Assembly A17J8 - Display Driver Board
W15 08562-60188 Wire Harness - Lowband Mixer Bias A14J11 - Frequency Control Board A8J4 - Lowband Mixer
W50
5063-0245
Wire Harness - OCXO Power (Includes A21 OCXO) A21 - OCXO Power Terminals A15J306 - RF Board
W55 5062-6471 Wire Harness - Volume Control / Speaker / Earphone Speaker/Earphone/Volume Control A4J6 - DC Logger Board
W62
8120-8482
Wire Harness - Backlight Power A17J6 - Display Driver Board A17A1 - Inverter Board
A1W1 8121-0033 Wire Harness - Probe Power Probe Power Filter Board A1A1J3 - Front Panel Keyboard
FL4
5061-9032
Wire Harness - Line Module Assembly Rear Panel - AC Input A6J10 - Power Supply Assembly
W18
5062-0721
Cable - SMB/BNC - White/Violet - LO Sweep A14J7 - Frequency Control Board Rear Panel J8 - LO SWP OUTPUT
W19 5062-0723 Cable - SMB/SMA - Gray/Orange - Option 001 A15J803 - RF Board Rear Panel J10 - 2nd IF OUT
W20
5062-0717
Cable - SMB/SMB - Blue - 0 Span Video A2J5 - Controller Board A3J103 - Interface Board
W22 5062-0709 Cable - SMB/SMB - Black - 10 MHz Freq Count A2J9 - Controller Board A15J302 - RF Board
W23
5062-0719
Cable - SMB/BNC - White/Orange - External Trigger In A3J600 - Interface Board Rear Panel J5 - EXT/GATE TRIG INPUT
W24 5062-0720 Cable - SMB/BNC - Green - Video Out A3J102 - Interface Board Rear Panel J4 - VIDEO OUT
W25
5062-0718
Cable - SMB/BNC - Yellow - Blanking Out A3J601 - Interface Board Rear Panel J6 - BLKG/GATE OUTPUT
W27 5062-0714 Cable - SMB/SMB - Orange - Filtered 10.7 MHz IF A4J3 - DC Logger Board A5J5 - IF Board
W29
5062-0711
Cable - SMB/SMB - Violet - 10.7 MHz IF A5J3 - IF Board A15J601 - RF Board
W31 5062-0722 Cable - SMB/BNC - Gray - 10 MHz Reference In/Out A15J301 - RF Board Rear Panel J9 - 10 MHz IN/OUT
W32
5063-1638
Cable - SMB/MCX - Gray/Violet - Sampler IF A15J101 - RF Board A14J501 - Frequency Control Board
W33 5062-0706 Cable - SMB/SMB - Gray/Brown - 2nd LO Drive A13J4 - Second Converter A15J701 - RF Board
W34
8120-6367
Cable - SMA/SMA - 7GHz Filter to Sampler FL3J2 - 7.0 GHz Low Pass Filter A15U100J1 - RF Board Sampler
W35 5062-0710 Cable - SMB/SMB - White/Red - Internal 2nd IF A13J2 - Second Converter A15J801 - RF Board
W36
5062-0725
Cable - SMB/SMA - Gray/Blue - External 2nd IF A15J802 - RF Board Front Panel J3 - IF INPUT
W37 5062-0707 Cable - SMB/SMB - Gray/Green - 10 MHz Reference A15J303 - RF Board A14J301 - Frequency Control Board
