Agilent Technologies 8565EC Service Guide

Cable Assemblies
Reference
Designator
Part Number Description From To
W40
5062-0724
Cable - SMB/BNC - Gray/White - CAL Out A15J501 - RF Board Front Panel J5 - CAL OUT
W48 8120-5660 Cable - SMB/SMA - RYTHM IF Out to 2nd Converter In A10J1 - RYTHM A13J3 - Second Converter
W49
5062-4892
Cable - SMB/SMB - Gray/Red - OCXO Output A21J1 - OCXO Output A15J305 - RF Board
W51 5062-6478 Cable - SMB/SMB - Gray/Yellow - 10 MHz Reference A4J7 - DC Logger Board A15J304 - RF Board
W52
5062-6477
Cable - SMB/SMB - White - 10.7 MHz CAL Signal A4J8 - DC Logger Board A5J4 - IF Board
W53 5062-6476 Cable - SMB/SMB - Brown - Frequency Counter A2J13 - Controller Board A4J5 - DC Logger Board
W54
5062-6475
Cable - SMB/SMB - Red - Video A3J101 - Interface Board A4J4 - DC Logger Board
W58 5062-0722 Cable - SMB/BNC - Gray - Option 005 A14J20 - Frequency Control Board Rear Panel J11 - ALT SWP OUT
W61 8120-5026 Cable - SMB/SMB - Gray - Display 10MHz A2J10 - Controller Board A17J7 - Display Driver Board
W28
5022-0915
Semi-Rigid Cable - LOMA to RYTHM A7J3 - LOMA A10J4 - RYTHM
W30 5022-3707 Semi-Rigid Cable - LOMA to FL3 A7J5 - LOMA FL3J1 - 7.0 GHz Low Pass Filter
W38
5022-3708
Semi-Rigid Cable - YTO Out to LOMA In A11J2 - YTO A7J1 - LOMA
W39 5022-2830 Semi-Rigid Cable - LOMA to Lowband Mixer A7J4 - LOMA A8J3 - Lowband Mixer
W41
08564-20019
Semi-Rigid Cable - RF Input to Attenuator In Front Panel J1 - RF INPUT A9J1 - Input Attenuator
W42 5022-3790 Semi-Rigid Cable - LOMA to EXT Mixer LO Output A7J6 - LOMA Front Panel J4 - LO Output
W43
5022-0908
Semi-Rigid Cable - Attenuator Out to SBTX In A9J2 - Input Attenuator A12J13 - SBTX
W44 5022-1151 Semi-Rigid Cable - A10 Lowband Out to FL1 In A10J2 - RYTHM FL1J1 - 2.9 GHz Low Pass Filter
W45
5022-2828
Semi-Rigid Cable - FL1 Out to Lowband Mixer In FL1J2 - 2.9 GHz Low Pass Filter A8J1 - Lowband Mixer
W46 5022-0907 Semi-Rigid Cable - LOMA to SBTX A7J2 - LOMA A12J4 - SBTX
W47
5022-2829
Semi-Rigid Cable - Lowband Mixer Out to SBTX A8J2 - Lowband Mixer A12J5 - SBTX
W56 5022-0910 Semi-Rigid Cable - SBTX IF Out to FL2 In A12J1 - SBTX FL2J1 - 4.4 GHz Low Pass Filter
W57
5022-0184
Semi-Rigid Cable - FL2 Out to 2nd Converter Lowband In FL2J2 - 4.4 GHz Low Pass Filter A13J1 - Second Converter
Flexible RF Cables (continued)
Semi-Rigid Cables
