Agilent Technologies 8565EC Service Guide

Front Frame Replacement Parts
Item
Description
Part
Number
Quantity
Nameplate - 8564EC 08564-80055 1
Nameplate - 8564EC - Option 006 08564-80056 1
Nameplate - 8565EC 08565-80054 1
Nameplate - 8565EC - Option 006 08565-80055 1
2
Overlay - Connector Dress Panel 5181-8245 1
4
Knob - RPG 5041-9610 1
6
Nut - 3/8-32-THD - .094-IN-THK 2950-0043 1
7
Lock Washer - Internal - 3/8 IN - .377-IN-ID 2190-0016 1
8
Front Dress Panel 5181-8246 1
9
Probe Power Jack 5060-0467 1
10
Nut - 15/32-32-THD - .1-IN-THK 0590-1251 1
Adapter - COAX - SMA (f) to SMA (f) 1250-1666 2
Hole Plug - Option 327 (Not Shown) 6960-0171 1
12
Screw-Machine w/Lock-Washer - Pan-HD - M3X0.5 - 8MM-LG 0515-2145 12
13
Bumper Kit (Includes 4 Bumpers) 5062-4806 1
15
Catch Latch 5021-5483 2
Screw-Machine - Pan-HD - M2.5X0.45 - 6MM-LG 0515-0366 4
Lock Washer - Helical - 2.6MM-ID - 5.1MM-OD - 0.6MM-THK 2190-0583 4
17
Front Frame 5022-3662 1
18
RFI Shielding - Round Strip 8160-0520 1
19
Nut - 9/16-28-THD 0590-2563 1
20
Lock Washer - Internal - 3/8 IN - .377-IN-ID 2190-0016 1
21
Nut - 3/8-32-THD - .188-IN-THK 2950-0144 1
22
Connector - RF Input 5064-3970 1
24
Rubber Keypad 5041-9630 1
26
Line Switch Cable Assembly 5064-3966 1
28
Screw-Machine - Flat-HD - M3X0.5 - 5MM-LG 0515-1521 2
31
Screw-Machine w/Washer - Pan-HD - M2.5X0.45 - 6MM-LG 0515-1934 7
32
Potentiometer - 20K OHM +-20PCT - 0.25W 2100-4232 1
33
Washer - 1/4-IN - .26-IN-ID 3050-0014 2
34
Lock Washer - Internal - 1/4-IN - .256-IN-ID 2190-0067 1
35
Nut - 1/4-32-THD - .062-IN-THK 2950-0072 1
36
Knob - Volume Control 0370-3079 1
1
11
16
