38 Chapter1
General Information
Recommended Test Equipment
AM/FM Frequency range: 1 MHz to 200 MHz 8640B A
signal generator Frequency modulation mode 8642A
Modulation oscillator frequency: 1 kHz
FM peak deviation: 5 kHz
Counters
Frequency Output frequency: 10 MHz 5061B P,A
standard
Accuracy: <1 × 10
−10
Microwave Frequency range: 9 MHz to 26.5 GHz 5343A* P,A,M,V
frequency counter
Timebase accuracy (aging): <5 × 10
−10
/day
Option 001
External frequency reference input
Universal Modes: TI A→B, frequency count 5334A/B P
counter Time interval measurement range: 100 ns to
120 s
Frequency count range: 400 Hz to 11 MHz
Frequency resolution: 1 mHz
Timebase accuracy (aging): <3 × 10
−7
/month
External 10 MHz reference input
Receivers
Spectrum analyzer Frequency range: 300 kHz to 7 GHz 8566B* P,A,T
Relative amplitude accuracy:
(for Option 002) 300 kHz to 2.7 GHz: <±1.8 dB
300 kHz to 7 GHz: <±4.0 dB
Absolute amplitude accuracy:
3.9 GHz to 6.9 GHz: <±2.7 dB
Frequency accuracy:
<±10 kHz at 7 GHz
Spectrum analyzer Frequency range: 300 kHz to 7 GHz 8566B* A,T
Amplitude range: −70 dBm to +20 dBm
Measuring Compatible w/power sensors 8902A* P,A,T,
receiver dB relative mode M,V
Resolution: 0.01 dB
Reference accuracy: <±1.2%
Sensors
Table 1-4 Recommended Test Equipment
Instrument Critical Specifications for Equipment
Substitution
Recommended
Model
Use
