380 Chapter8
ADC/Interface Section
Introduction
Figure 8-1 A3 Test Connectors
Table 8-2 Table 8-1. W2 Control Cable Connections (2 of 2)
Signal A3J2
(pins)
A4J2
(pins)
A5J2
(pins)
A14J2
(pins)
A15J2
(pins)
A GND 35* 35 16 35 35
RF GAIN 36* ———36
LO3 ERR ———3737*
A GND 38* 38 13 38 38
LVFC_ENABLE 39* 39
FC ERR 40 40*
A GND 41* 41 10 41 41
YTO ERR 42 42*
+10V REF 43* 43 43
A GND 44* 44 7 44 44
SCAN RAMP 45 45*
VIDEO
TRIGGER
46*————
A GND 47* 47 4 47 47
NC —————
R/T DAC2 49* ————
R/T DAC1 50* 50
* Indicates signal source.
