Agilent Technologies 8565EC Service Guide

410 Chapter8
ADC/Interface Section
A3 Assembly Control Circuits
Table 8-9 Demultiplexer A3U410 Truth Table
Selected Output Line IA1 IA2 IA3
Pin 15, LSCAN_KBD L L L
Pin 14, LDACU1 H L L
Pin 13, LDAC1 L H L
Pin 12, LDAC2 H H L
Pin 11, LDAC3 L L H
Pin 10 H L H
Pin 9, LTIMER L H H
Pin 7, LADC_REG1 H H H
Table 8-10 Demultiplexer A3U500 Truth Table
Selected Output Line IA0 IA1 IA2
Pin 15, LSENSE_KBD L L L
Pin 14, LINT_PRIOR H L L
Pin 13, LADC_DATA1 L H L
Pin 12, LDAC_DATA0 H H L
Pin 11, HCNTR_LD0 L L H
Pin 10, HCNTR_LD1 H L H
Pin 9, LRPG_RD L H H
Pin 7, LADC_REG0 H H H
