Chapter 12 607
RF Section
A9 Input Attenuator
Table 12-4 Attenuator Control Truth Table (W11 connected or
disconnected from A14J6)
A14U421
ATTEN
Setting
(dB)
10 dB 30 dB 20 dB
Pin
16
Pin
15
Pin
14
Pin
13
Pin
12
Pin
11
0 LFLFLF
10 FLLFLF
20 LFLFFL
30 FLLFFL
40 FLFLLF
50 LFFLFL
60 FLFLFL
F Floating (≈0.2 V) L ≈ 0.6 V
