Issue 2 - 07/00 1-17
Welcome to aurora
Sonata
- Section 2
DC Power in
RJ45 & FCC684-4
Telecomms
Interfaces
SELV (Safety Extra Low Voltage)
TNV1 (Telecommunications Network
Voltage - as classified in EN60950)
RS232
SELV
Telecommunications Safety
Safety StatusConnector
Cables used with aurora
Sonata
The following cables are available for use with the basic tester:
• 2m RS232 cable with 8-pin mini-Din at tester end
and 9-pin D socket at remote end, wired for direct
connection to a PC communications port.
• 9-pin to 25-pin D type converter (optional).
• mains battery charger/eliminator appropriate to the
country of use
For Basic Rate S interface testing:
• 2m RJ45 to RJ45 100R cable, supplied as standard
• monitor ‘T’ piece (optional)
For Basic Rate U interface testing:
• 2m FCC68 4-4 to banana plugs 100R cable, also
connecting to crocodile clips. Supplied as standard
with the U interface, but not used in the US.
For Primary Rate testing, the set of cables supplied as standard
varies according to country and may include the following:
• 2m RJ45 to RJ45 100R
• 2m RJ45 to 4mm banana plugs
• 2m RJ45 to BNC connector
• 2m RJ45 to BT type 43 connector
Other cables are supplied on request as optional accessories.
