Issue 2 - 07/00 2-11
Getting Started - Section 1
-4-
Remove the belt hook from the top of the
cover.
-5-
Replace the bolt in its holder by sliding it back
in and pushing down to secure it in place.
Warning: Belt hook bolt
Always keep the bolt in its holder. If you lose it you will not
be able to replace the belt hook, and the case will not be
watertight.
-6-
Replace the battery pack cover:
• Slide the cover back down into place.
• Push the screw down and turn it
clockwise to tighten.
Warning: Tightening the screw
Make sure the screw is tight enough to avoid the cover coming
off when you try to hang up aurora
Sonata
from its belt hook.
Replacing the belt hook
-1-
Remove the battery pack cover and take out
the bolt from the belt hook release mechanism,
as described in Removing the belt hook above.
-2-
Replace the hook by placing it in the socket at
the top of the battery pack cover with the
opening pointing towards the back of the unit.
Line up the bolt holes in the hook with the
holes in the cover.
-3-
Replace the bolt in its holder and secure it by
pushing down.
-4-
Replace the cover as described in Removing the
belt hook above.
