Agilent Technologies InfinityLab LC Series - Introduction to Maintenance

Agilent InfinityLab LC Series Vialsamplers User Manual 223
8Maintenance
Introduction to Maintenance
Introduction to Maintenance
The module is designed for easy maintenance. Maintenance can be done from
the front with module in place in the system stack.
Figure 33 Overview of the Vialsampler
Status indicator
Needle assembly
Drawer
Column shelf
Leak drain
Power switch
