Agilent Technologies InfinityLab LC Series - Analytical-Head Assembly (900 µL)

Agilent InfinityLab LC Series Vialsamplers User Manual 296
9 Parts and Materials for Maintenance
Analytical-Head Assembly (900 µL)
Analytical-Head Assembly (900 µL)
Figure 46 Analytical head assembly (900 µL)
Item p/n Description
G7129-60083 Analytical Head Assembly 900 µL
1 G7129-27790 Analytical-Head 900 µL
2 0905-1294 Metering Seal, 900 µL
3 5001-3764 Seal Support, 900 µL
4 G7129-60006 Analytical Head Adapter
5 0515-0850 Screw, ST, M4x0.7, Hex 4 mm
6 G4267-60462 Piston, 900 µL, Sapphire
1
2
3
4
5
6
NOTE
With the 900 µL analytical head, the maximum system pressure is limited to
400 bar.
