Agilent Technologies InfinityLab LC Series - Analytical Head Assembly (40 μL)

Agilent InfinityLab LC Series Vialsamplers User Manual 297
9 Parts and Materials for Maintenance
Analytical Head Assembly (40 μL)
Analytical Head Assembly (40 μL)
Figure 47 Analytical head assembly (40 µL)
Item p/n Description
G7129-60084 Analytical Head Assembly 40 µL
1 G7129-27704 Analytical-Head 40 µL
2 0905-1717 Metering Seal, 40 µL
3 G7129-60184 Seal Support, 40 µL
4 0515-1052 Screw, ST, M3x0.5, Hex 2.5 mm
5 G7129-60006 Analytical Head Adapter
6 0515-0850 Screw, ST, M4x0.7, Hex 4 mm
7 5067-5920 Piston, 40 µL, Zirconia
1
2
3
4
5
6
7
