3Using the Module
Vial Drawers and Trays
Insert a Vial Into the Sampler
NOTE
Attempting to insert a new vial into the sampler while the gripper arm is moving
might lead to aborting the ongoing analysis.
1 Open the doors of the module.
NOTE
For accessing the left drawer, it is sufficient to open the left
door only.
2 Pull out the vial drawer into which you want to insert the
vial.
3 Insert the vial into an appropriate position of the drawer. 4 Push the vial drawer back into place.
