3Using the Module
Vial Drawers and Trays
Figure 18 Numbering of drawer position (Drawer for 50 x 2 mL Vials Classic)
Figure 19 Numbering of tray position (External tray)
1
50
51
100
201
202
203
204
205
206
(Waste Disposal)
