Table 67 shows a different mapping enabled when the user applies one of three predefined
egress QoS profiles in the 4-class bundle configuration only.
The MLPPP class queue parameters and its scheduling parameters are also configured by
applying one of the three predefined egress QoS profiles to an MLPPP bundle.
Table 68 and Figure 51 provide the details of the class queue threshold parameters. Packets
marked with a high drop precedence, such as out-of-profile, by the service or network ingress
QoS policy will be discarded when any class queue reaches the OOP threshold. Packet with
a low drop precedence marking, such as in-profile, will be discarded when any class queue
reaches the max threshold.
3 L1 Non-Expedited 2 2 1
2 AF Non-Expedited 2 2 1
1 L2 Non-Expedited 3 2 1
0 BE Non-Expedited 3 2 1
Table 66: Default Packet Forwarding Class to MLPPP Class Mapping (Continued)
FC ID FC Name Scheduling Priority
(Default)
MLPPP Class 4-
class bundle
MLPPP Class 3-
class bundle
MLPPP Class
2-class bundle
Table 67: Packet Forwarding Class to MLPPP Class Mapping
FC ID FC Name Scheduling Priority
(Default)
MLPPP Class
(MLPPP Egress QoS profile 1, 2, and 3)
7 NC Expedited 0
6 H1 Expedited 0
5 EF Expedited 1
4 H2 Expedited 2
3 L1 Non-Expedited 2
2 AF Non-Expedited 2
1 L2 Non-Expedited 2
0 BE Non-Expedited 3
